Ultimate Power Electronics and Electrical Protection Bundle

"Ultimate Power Electronics and Electrical Protection for Electrical Engineering"

This magnificent 51-hour course will help you have a kick start in power electronics including rectifiers, AC choppers, DC choppers, and inverters. In addition to the basics of electrical protection such as overcurrent protection, differential protection, distance protection, circuit breakers, and fuses.

Throughout the power electronics course, you will learn:

• The applications of power electronics and the definition of a power electronic circuit.

• Different types of switches such as diodes, thyristors, GTO, BJT, IGBT, Mosfet, etc.

• The different AC/DC converters (rectifiers) such as half-wave and full-wave rectifier single-phase circuits in uncontrolled, half, and fully controlled bridges. In addition to the different three-phase rectifier circuits.

• AC chopper circuits or AC/AC converters in the case of R load, L load, RL parallel, RL series load, and capacitive loads. In addition to the integral cycle control of an AC chopper.

• DC choppers or DC/DC converters such as the step-down DC chopper with R and R-L-E load, and the step-up DC chopper with R, RL, and RE loads. Moreover, the buck, boost, and buck-boost regulator circuits.

• Inverter or DC/AC converters including single-phase half-bridge R-load, single-phase half-bridge RL-load, single-phase bridge inverter R-load, single-phase bridge inverter RL-load, and the three-phase inverters. Furthermore, the single, multiple, and sinusoidal pulse width modulations.

You will learn also the simulation using the MATLAB Simulink program:

• Single-phase half-wave controlled and bridge-controlled rectifiers.

• Single-phase AC chopper with R and RL load

• DC-DC converters such as buck, boost, and buck-boost regulators.

• Single-phase half-bridge, bridge inverters, and three-phase inverters.




Throughout the electrical protection course, you will learn:

• The different components of the electrical protection system, zones of protection, the trip circuit of the electrical system, the primary and backup protection, and the fault clearing time.

• The different types of relays such as directional power relays, overcurrent relays, distance relays, plain impedance relays, directional impedance relays, modified impedance-type distance relays, reactance-type distance relays, Mho or admittance distance relays, and more.

• The principle of operation and selection of low-voltage circuit breakers

• The principle of operation of earth leakage circuit breaker or residual current CB

• The selection of medium voltage circuit breakers

• The types of low voltage and high voltage fuses

• Sizing of breakers, fuses, and disconnecting switches for motors, non-motor applications, and much more according to the NEC




In addition to the LogixPro course:

This is the only course out there that can teach you the basics of PLC programming with fun and awesome simulations.

Logixpro program is an interesting and useful simulator for the simulation of different procedures such as moving belts, garage openings, and closing, a mixer that consists of a tank in addition to some pipes of different liquids, and many more!

This program helps learn ladder programming and PLC with an easy and interactive simulation method.

Bonus Gift:

​You will also get the slides for the Ultimate Power Electronics and Protection bundle for those who are interested in them or having them as a revision for themselves

• More than 250 Pages of Rectifiers and Basics of Power Electronics

• 45 Pages of AC Choppers

• 78 Pages of DC Choppers

• 90 Pages of Inverters

• 153 Pages of Electrical Protection

• 36 Pages of NEC Sizing for Overcurrent and Overload

• 26 Pages on Breakers and Fuses

• 72 Pages on Disconnect Switches

Take this bundle if you've been looking for ONE COURSE BUNDLE with in-depth insight into power electronics, electrical protection, and PLC basics.
